1. Strictly abide by the various operating procedures of stranding machine to ensure safe production.

2. According to the lay length requirements specified by the process, install the corresponding pulleys and lay length gears according to the lay length table.

3. Install the pay-off reel, and pull the copper wire through the wire storage of the pay-off rack to the cable inlet end of the host, and then pass into the host through the lead input. One of them must be guided by the meter counter (otherwise, the meter counter will not count after it is turned on).

4. Install the take-up reel, and pass the wires passing through the host through each guide and twist the bow, and finally wind a few turns on the take-up reel.

5. Turn on the main power switch in the electrical cabinet of the host, and set the length budget of the meter counter according to the process requirements. If the original length of the original meter is not zero, it should be cleared.

6. Turn the six toggle switches on the side of the mainframe electric control cabinet to the ON position.

7. Check whether the tray at the bottom of the main unit has been lowered to the end. If it has not been lowered to the end, release (turn it counterclockwise) the switch of the oil pressure pump to lower it to the end, and close the door and cover.

8. Turn the "speed setting potentiometer" on the main machine's electrical cabinet fully counterclockwise, press the "motor start" button, and then slowly turn the "speed setting" potentiometer clockwise, and the machine will start to run , The running speed is indicated by the tachometer.

9. After reaching the predetermined length, the machine will automatically stop. After the twisted bow is completely stopped, the hood can be opened and the unloading door can be lowered. Turn off the oil pump switch again (turn it clockwise), pull out the oil pump hook, and squeeze the oil pump handle to raise the tray against the take-up reel. After unloading the spool, in order to prevent the hydraulic handle from falling off, hook the hook to the handle of the oil pump.

10. During operation, if a wire break is found, the machine will automatically stop in an emergency. In the event of an unexpected situation, you can press the "Emergency Stop" button when you need an emergency stop, and the machine will stop quickly.

11. When wire breakage or wire change occurs, the connector should be small and reliable. Before the joint reaches the take-up reel, it should run at low speed. At this time, it should be operated in jog mode. The jog operation method is as follows: open the door cover, press the micro switch with your left hand, and press the "inch button" with your right hand, the bow will run at low speed. Release this button to stop running. During the inching process, the joint should be observed visually. After the joint reaches the take-up reel, the door cover can be covered and the normal operation can be changed.
